I. Product Overview
Search and rescue
In complex and harsh terrain conditions and natural environments, amphibious all-terrain vehicles can enable search and rescue team members and the rescue equipment they carry to reach the rescue site quickly, reduce the consumption of walking gear, and complete the last mile of emergency rescue tasks within the best five minutes. The amphibious all-terrain vehicle can be equipped with point-to-winch, rescue stretcher assembly, searchlight, warning light, alarm, unhooking, demolition tools and other equipment, providing rescue support for the rescue team and enabling safer rescue of the injured and evacuation of the masses.
Fire fighting and extinguishing
When a fire breaks out, in complex terrain and environment, there is no time to wait for heavy rescue equipment to arrive at the scene smoothly and in time. The amphibious all-terrain vehicle can be immediately ready to deploy firefighters and use the spray and foam equipment carried on the vehicle to suppress the fire source at the scene. Equip the same facilities to protect fire-prone areas and prevent risks before they occur.
Mountain rescue
Mountain rescue means that rescue vehicles must have strong adaptability to different terrains and natural climates. Rescue vehicles need to have excellent climbing ability and strong passability. Not only does it have to deal with the tests of various harsh natural environments such as steep slopes, boulders, jungles, snowfields and rivers, but it also needs to be capable of carrying rescue personnel and equipment in mountainous areas without roads. Amphibious all-terrain vehicles can well undertake this arduous task.
Water rescue
For areas with frequent floods, water rescue tasks are indispensable. However, floods and urban waterlogging are often accompanied by bad weather and rough terrain. Inflatable boats need to be carried by different means of transportation multiple times and transferred several times. Amphibious all-terrain vehicles can easily pass through environments such as water flooding, mud, and swamps without the need for manual transportation. They can freely switch between land driving and water walking, and arrive at the scene for rescue in the shortest time.
Medical rescue
The amphibious all-terrain vehicle provides auxiliary services for ambulances on rough roads. When ambulances cannot safely pass through areas, the amphibious all-terrain vehicle can climb over various types of obstacles and promptly reach the location where the injury occurs. In an emergency, you can take a direct route to reach the scene more quickly. Additional stretchers and anti-toppling structures mean that patients or injured people can receive safe and rapid medical care.

Ii. Scope of Application
Fire fighting and extinguishing
Search and rescue
Mountain rescue
"Water rescue"
"Medical rescue"

Iii. Product Features
1) Fully amphibious, capable of wading and crossing water to pass through water obstacles
2) It can be used as a towing trailer
It can accommodate up to 8 passengers at most
4) It can be used for search and rescue
5) It can be used as a disaster and danger response vehicle
6) It can be used as an emergency medical service vehicle
7) It can be used for coastal patrol
8) ★ Multiple types of equipment (such as fire rescue devices) (optional)
9) ★ Equipped with location positioning function (optional)
10) ★ Equipped with 4G/5G information transmission function (optional)
11) ★ Leakage detection and alarm function (optional)
12) ★ It has long-distance intercom function and amplification function (optional)
13) ★ Water depth detection (optional)

Iv. Main Technical Indicators
Main technical parameters:
1. Body dimensions: ≤3400*1600*1350mm
2. The vehicle body is made of polyethylene and formed by vacuum forming. The vehicle components are designed in a closed manner
3. ▲ Total vehicle weight: ≤770kg
4. ▲ Minimum ground clearance: ≥220mm
5. Wheelbase: ≤680mm×3
6. Track: ≤1500mm
7. Engine type: Four-stroke, overhead valve (OHV)
8. Displacement: ≥999CC
9. Horsepower: ≥37HP
10. Maximum torque: ≥74 N.m
11. Rated speed: ≥3600rpm
12. Clutch mode: Continuously variable transmission (CVT), belt drive
13. Gear shifting modes: 2 forward gear, neutral gear, reverse gear
14. Fuel grade: 92#
15. Fuel tank capacity: ≥40L
16. Starting method: Electric start with key switch
17. Drive mode: Land: 8-wheel drive;
18. Integrated digital instrument panel: speedometer, tachometer, odometer, oil pressure display, handbrake indicator light, lighting lamp, etc
19. The vehicle is equipped with an engine fault diagnosis system
20. ▲ Maximum speed: On land: ≥50km/h; Water: ≥5km/h, tires ≥8km/h(pump push)
21. ▲ Vehicle load: 469.3kg on land, 371kg on water
22. ▲ Vehicle load: ≥6 people on land and ≥4 people on water
23. Minimum turning radius: ≤699.7mm
24. ▲ Maximum climb: ≥35°
25. Braking method: Caliper disc hydraulic braking
26. Transmission: Automatic transmission
27. Steering mode: Progressive slip steering
28. Tire type: Duck fin tires are adopted
29. Approach Angle: ≥50°, departure Angle ≥50°
30. Maximum inclination Angle: ≥35°
31. ▲ Obstacle crossing: ≥386mm
32. ▲ Crossing trenches: ≥500mm
33. Running time: ≥10 hours to 13 minutes
34. Throttle mode: Variable speed throttle handle
35. ▲▲ Water Rescue Integrated Monitoring Device: Wireless video transmission: Real-time video can be viewed through the APP end. Video storage: Equipped with a 256G memory card. Intercom function: Communication can be conducted when the APP end is 3000m away from the hull end. Amplification function, amplification distance ≥500m. Leakage detection function: Equipped with a handheld leakage detector. (Optional)
